Home>Products>Processing Equipment Division

Item		Unit	BSF-A4
Size of workpiece		mm	D φ6～φ25 L 220～370
Control unit			FANUC 18i-TB
Spindle motor			FANUC alfa B112S/2000i
Spindle speed		min-1	500　～　8,000
Slide	Travel	mm	X : 80, Y : 150, Z : 150
	Rapid traverse	m/min.	m/min.
	Combination		X and Z slides on the right and the left of the spindle
			Closed loop
	Type		Linear (gang) turret/vertical
	Number of tools		5 tools each on the right and left slides
Least command incremental		mm	0.001
Floor		mm	1,730 (L) x 1,100 (W)
Weight		kg	1,500
