| Items |
Unit |
OM-430 |
| Capacity |
Size of machinable work |
mm |
100x100x100 |
| Control unit |
|
|
FANUC 21i-MA |
| Spindles |
Spindles |
Horizontal |
|
|
4 |
| Vertical |
|
|
2 |
| Distance between quills |
mm |
|
120 |
| Speed |
min.-1 |
1,000-7,000 |
| Rigid spindle speed |
min.-1 |
max: 3,600 |
| Collet |
|
New baby chuck for DAISHOWA SRB-13 |
| Quill diameter |
mm |
|
80 |
| Diagonal unit |
Max milling diameter |
mm |
|
3 |
| Spindle speed |
min.-1 |
5,000¢¦60,000 min |
| Column |
Travel |
mm |
X:390,Y:150,Z:150 |
| Rapid traverse |
m/min. |
X:15, Y:12, Z:12 |
| Least command incremental |
mm |
|
0 |
| C axis |
Index degree |
|
|
0 |
| Rotation speed (Rapid traverse) |
|
60 rpm |
|
| Horizontal |
AC spindle (rigid tap available) |
kw |
|
1 |
| Vertical |
AC spindle (rigid tap available) |
kw |
|
1 |
| Column |
0.9kW (AC servo) |
|
X, Z, Y axis |
| C axis |
0.4kW (AC servo) |
|
C axis |
| Floor |
Floor |
mm |
1,240(W)x1,595(D) |
| Weight |
Weight |
kg |
|
2,500 |
|
|
 |
| |
|
|
|
|
 |
|
