| Item |
Unit |
E-32v |
| Slide travel |
Travel |
X axis ( horizontal right-left ) |
mm |
# |
| Y axis ( horizontal front-rear) |
mm |
# |
| Z axis ( vertical ) |
mm |
# |
| Feed |
mm/min. |
X, Y, Z: 5,000 |
| Rapid traverse |
m/min. |
X, Y, Z: 12 |
| Table |
Working area on the table |
mm |
250 x 250 |
| Turn of the trunnion ( A axis) |
|
0¡¡¢¦¡¡95¡Æ |
| Turn of the table (C axis ) |
|
0¡¡¢¦¡¡¡¾360¡Æ |
| Spindle |
Nose |
|
BT30? 7/24 taper |
| Speed |
min-1 |
# |
| Motor |
kw |
FANUC Model alfa 3
3.7/5.5(conti./30min.) |
| Feed |
mm/min. |
x, Y, Z: 5,000 |
| Rapid traverse |
m/min. |
|
| ATC |
Tool shank |
|
BT-30 |
| Stock of tools |
|
24 tools(standard) /
60 tools (option) |
| Selection of tools |
|
Random access , fixed address |
| Floor |
|
mm |
1,275 ( L ) x 2,265 (W) |
| Weight |
|
kg |
# |
| Control unit |
|
|
FANUC 18i-MB5 |
|
|
|
|
|
 |
|
